034Motorsport's Black Friday Sale Pricing is Available from November 21st, 2022 - December 12th, 2022
Our best-selling upgrades for the B9 Audi SQ5 can be found by heading over to our website to browse upgrades by vehicle.
034Motorsport Dynamic+ Stock Turbo World Record B9 S4 Tuning is available at 10% off MSRP!
Stock Turbo Tuning:
Stage 1 - $765.00
Stage 1+ - $810.00
Stage 2 - $855.00
Stage 2+ - $900.00
Dynamic+ End User Flashing Kit - $138
Our Dynamic+ Tuning for stock turbo comes with fueling options for 91, 93, and E85 for Stage 1(+) & Stage 2(+)!
Stage 3 TTE710:
Stage 3 - $1215.00
Our Stage 3 Dynamic+ Tuning for the TTE710 comes with fueling options for 91, 93, 104, E60, and E85
Power Gains:
Stock: 350 HP / 391 TQ
Stage 1 91: 397 HP / 491 TQ
Stage 1 93: 431 HP / 567 TQ
Stage 1 E85: 486 HP / 601 TQ
Stage 1+ E85: ~15 HP / 25 TQ Gain @2,700-4,800RPM over Stg 1 E85
Stage 2 91: 454 HP / 542 TQ
Stage 2 93: 476 HP / 576 TQ
Stage 2 E85: 510 HP / 616 TQ
Stage 2+ E85: ~13 HP / 20 TQ Gain @2,700-4,800RPM over Stg 2 E85
Stage 3 91: 528 HP / 553 TQ
Stage 3 93: 604 HP / 620 TQ
Stage 3 MS109/260GT+: 693 HP / 685 TQ
Stage 3 E60 Mix: 720 HP / 720 TQ
Stage 3 E85 Pump: 643 HP / 650 TQ
Product Description:
The 034Motorsport Dynamic+ Stage 1, Stage 2, and Stage 3 TTE710 Tuning Software for Audi B9/B9.5 S4/S5/SQ5 equipped with the EA839 3.0T V6 engine is designed to transform the driving experience of your vehicle! Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the ECU safely and effectively increase the power output of the turbocharged V6 in a refined manner. The result is a significant improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.
034Motorsport B9 Audi S4/S5/SQ5 EA839 3.0T Dynamic+ Performance Software was developed entirely in-house on 034Motorsport's Development B9 S4, B9.5 S4, and B9 SQ5. The calibrations were then refined on multiple enthusiast-owned beta tester cars around North America.
Included at no extra cost is the Stage 1 Dynamic+ Performance TCU Software for B9/B9.5 Audi S4, S5, or SQ5 models equipped with the AL552 8-Speed ZF8 transmission. At an extra cost, upgrade to the Stage 2 TCU Tuning to further enhance the shifting and acceleration of your ZF8 Equipped 3.0T! Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the AL552 TCU safely and effectively raise the torque limits of the ZF8, allowing your car to make use of Stage 1, Stage 2, and Stage 3 TTE710 Performance Software.
DYNAMIC+ ECU & TCU FEATURES:
TRUE LAUNCH CONTROLFrom the factory, conventional launch control strategies are not activated in the ECU. 034Motorsport’s skilled Calibration team has properly engineered and implemented true launch control functionality to the EA839 and AL552 ZF8. Through OEM Calibration strategies of timing reduction, Boost Control PID optimization, and torque target management, the system is able to allow for a maximum 3,000-3,500 RPM launch targeting 22psi for up to 8 seconds, making for a strong and smooth launch! Unlike the factory ECU that tries to “push through the brakes” on a standing brake launch, the 034Motorsport Dynamic+ calibration will allow proper loading of the engine without pushing through the brakes as hard, and properly targets a specified RPM to launch at.
THERMAL MANAGEMENT SAFETY STRATEGIES
With increased power, comes increased heat. With increased heat, comes the need for additional management. For both charge air temperature and engine coolant temperature, 034Motorsport has implemented key safety features to keep your engine running optimally and safely in virtually any condition - just like the OEM calibration. Substantial effort was spent on balancing the trade off of charge temp for power, and improving the compressor efficiency so that it doesn't generate too much charge temp.
Charge Air Temp: When the charge temp exceeds 80*C there is a reduction in power output. When the charge temp exceeds 85*C there is a more significant reduction in power output. This charge temp limitation is there to prevent knock events, which can severely damage a motor. With these safety measures in place, you can confidently drive your car, from the top of Pikes Peak to Death Valley, knowing the factory ECU has optimal performance and safety covered..
Coolant Temp/Fan Strategy: From the factory, Audi likes to run hotter water temps to reduce fluid friction losses from cooler, more viscous oil. While better for efficiency, this strategy becomes a safety issue when loads and heat are increased. 034Motorsport calibrators have rescaled the coolant temperature targets and fan control strategies to target lower coolant temperatures when in higher heat conditions, allowing the car to run within a safe heat range rescaled for the added heat that comes from tuning the engine. Once again, this means that 034Motorsport calibrators have kept your confidence in safety fully intact from the OEM configuration.
RS-STYLE STARTUP REV ENABLED
Enjoy a nice start-up rev when turning the car on with our new RS-Style start-up program!
START/STOP BUTTON MEMORY
The Dynamic+ Tuning options for the EA839 3.0T all retain the Start/Stop engine functionality, but allow users to set memory for the system based upon preference. If you do not want the Start/Stop system to run, turn it off via the in-cabin button and the car will store that selection even after key cycling the car. If you would like it to stay on, select it to be on via the in-cabin button. This is done in a completely OEM fashion, helping enhance the overall experience of driving your car!
INCREASED POWER AND ACCELERATION DURING SHIFT EVENT
034Motorsport tuning safely applies more power throughout the shift event, increasing overall acceleration and performance.
ENHANCED CRACKLES IN DYNAMIC MODE
034Motorsport engineers have enhanced the crackles for maximum auditory pleasure! Crackles can be toggled on or off via Drive Select. They will be on in Dynamic and off in Comfort, giving you the ability to crackle when you want, and cruise quietly when you don't. In Individual, crackles can be toggled on or off via Engine Sound. NOTE: Launch Control Only Works in True Dynamic Mode.
EXHAUST FLAPS PERMANENTLY OPEN IN DYNAMIC MODE
From the Factory, Audi will open and close the exhaust flaps randomly, even in Dynamic mode. With 034Motorsport tuning, When set to Dynamic, the exhaust valves will now stay constantly open.
FREE REVVING IN NEUTRAL AND PARK
The rev-limiter is now removed while in Neutral and Park. Impress friends and annoy those around you with limitless ease!
FUEL SYSTEM OPTIMIZATION
While E85 provides substantial increases in power, it requires about 30% more fuel than standard pump gasoline per ignition cycle. Utilizing a variety of fuel stratified injection strategies, 034Motorsport calibrators have further optimized the factory fueling system to be able to adequately support full E85 on factory hardware for Stage 1 tunes.
ACCURATE BOOST AND TORQUE REPORTING
As with anything in life, it is always best to be truthful. This especially applies when it comes to reporting torque outputs in the ECU to the other control modules in the car, as well as displaying accurate boost readings to the driver via the boost gauge found on the Virtual Cockpit. With 034Motorsport Dynamic+ software, the ECU is reporting accurate torque values to critical systems like the TCU to ensure that all safety systems are intact in both control units, and the added torque from tuning is properly adjusted for when driving/shifting, including all safety systems designed to protect the engine and transmission.
What Makes Dynamic+ Different:
While many tuners can achieve great power figures that look impressive on a dyno sheet or a webpage, the key to a truly substantive and transformative software upgrade lies in the strategies employed to make power efficiently and safely. 034Motorsport Dynamic+ Software strives to retain as many OEM safety protocols as possible, and holistically recalibrate the entirety of the ECU and TCU to create what we call the Dynamic+ experience.
034Motorsport engineers develop special in-house tools that allow us to access the firmware and maps inside the factory ECU. This level of engineering is required to prevent workarounds and bandaids that many aftermarket companies resort to. 034Motorsport optimizes the ECU calibrations just like Audi engineers would, accessing the source of how the ECU controls the engine and making changes at the base level.
This is the only way 034Motorsport can ensure our calibrations meet our industry-leading standards for delivering ultimate power with unrivaled drivability, uncompromised reliability, and enhanced features and functionality beyond what is provided in the factory calibration.
CHECK IT OUT HERE
EMISSIONS DISCLAIMER
This product is sold for racing use as well as use on vehicles not registered for on highway use.
By purchasing this product, you understand that this product is sold for racing use as well as used on vehicles not registered for on highway use, and that it is not legal for use on highway or street vehicles.
