    Cool The #offroadaudi A8 D3 project is here...

    Guest-only advertisement. Register or Log In now!
    Sometimes ideas come from the least expected places and as ridiculous as they sound on paper they just have to be set in motion...

    During the first test outing with Gorman Motorsports pro-class naturally aspirated Polaris RZR we found that we ran out of space inside the tow vehicle for all of the supplies and team members to all get into the desert. Well as luck would have it the A8 D3 has air suspension and a lift mode, so why not give it a shot. The car performed amazingly well on dirt, loose gravel and deep sand, even with less than capable performance all-season tires.



    The idea was borne that every race driver needs a limousine back and forth from the event, but even better yet a limo that can turn on a dime, deliver a mechanic or needed spare parts and roll through the desert in air conditioned ease.



    The seed was planted and the inevitable just had to happen. After some research on the biggest tire diameters possible, some test fitments and months of gathering parts the slow build up process yielded this, enjoy!

























    The car features a host of useful upgrades that any chase vehicle for an offroad team would need. A custom installed CETE air suspension controller allows for the fun of -55mm front and rear for parking and 30mm of additional clearance in lift mode which is still fully switchable through the factory MMI. Hella lamps were custom wired up with dual relays and wired to the factory front fog light switch with a hidden cutoff just in case we don't want to blind anyone while using the fog lights normally. Factory Audi crossbars hold a Loadwarrior rack with a full sized spare, additional gas, a shovel for any sticky situations and a 5ft VHF/UHF antenna for longer range team communications. The car is fully stocked with hand tools, power tools, jump pack, air compressor, emergency equipment, first aid kit and plenty of space for mechanics, driver's and spares in the unlikely event the car becomes the primary chase vehicle during it's first race 8/18 for the BITD Vegas to Reno race.

    Lighting
    4x Hella Rallye 1000 Black Magic Lamps
    Lamin-X Fog Light Film (Incoming)

    Exterior
    European License Plate Holder
    Genuine Audi Crossbars
    Yakima Loadwarrior Rack
    Yakima Spare Carrier
    Yakima Shovel Holder
    2x 5 Gallon Jerry Cans
    3M Clear Bra

    Interior
    S-Line Post-Facelift Flat-Bottom Steering Wheel Package
    S8 D3 Shift Knob

    Electronics
    CETE Air Suspension Controller (Custom Installation)
    Suakoi 600A Jump Pack and Air Compressor
    Boafeng BF-F8HP 8W Dual Band Radio
    Tram 5ft Whip Antenna Directly Wired to Handheld Radio in Console
    6x USB Outlets and 5x Cigarette Style Outlets

    Wheels and Tires
    Pacer 17x7" Black Steel Wheels
    BFGoodrich 225/65-17 T/A K02 Tires
    H&R DRA 30mm Spacers
    56mm Hardened Wheel Studs
    Aerospeed Aluminum 21mm Lug Nuts

    Supplies and Tools
    10 Gallons of Gas
    Full Sized Spare
    Bully Tools Short Shovel
    Full Hand and Power Tool Kit


    If you are an offroad racing fan or just want to see an A8 well out of it's element, or maybe this is it's element, don't hesitate to follow both instagram feeds here starting Wednesday 8/16 forwards with the main event being 8/18 at 9AM PST when we begin chasing Gorman Motorsports RZR in their quest to finish this grueling 540 mile race:

    Europrice.us - - - - Gorman Motorsports

    If all goes well next year you'll see this #offroadaudi in Baja, Mexico...

    Cheers!

  2. #2
    Senior Member Two Rings dnovak33510's Avatar
    Join Date
    May 19 2014
    AZ Member #
    231839
    Location
    Tampa FL

    Please tell us more about this "custom installed CETE air suspension controller" that still allows control through the factory MMI

  3. #3
    Stage 2 Banner Advertiser Four Rings
    Join Date
    Aug 07 2008
    AZ Member #
    31696
    Location
    California

    Quote Originally Posted by dnovak33510 View Post
    Please tell us more about this "custom installed CETE air suspension controller" that still allows control through the factory MMI


    The CETE module is mainly offered for newer Audi models with air suspension, C7, D4, etc. However the systems in many of the earlier cars with air suspension are very similar but producing a plug and play harness would be near impossible or extremely expensive part and time wise because of the large ECU style plugs the D3 models use at the air suspension controller.

    With that in mind I was able to determine what wiring was being used on the newer installations and translate that for custom use on the D3 models. Hiding behind the glovebox is the air suspension controller on the D3. The CETE module required power, ground, wiring from each level sensor, a reference lead and CAN-BUS wiring. Then firmware that worked specifically with this module was loaded and voila.

    You can see more details here on the D4 product page:

    Controller Package | A8, S8 Air Suspension

    The controller allows you to offset each suspension setting and save that as a profile. What that means is every time you select Dynamic through the MMI if you have saved a -15mm profile the car will always be 15mm lower on dynamic. Each factory MMI setting can have a profile that is lower or higher and you use the app to set this. You can also change on the fly with the app, but most people set their desired offset and use the factory MMI to change the settings.

    I can do a video to show how the system works and I gotta say it works a charm.

    There is also show mode which you can set all the way down to -55mm and obviously it will produce the super low heights you see in photos above.

    If there are any A8/S8 D3 owners interested I can work with CETE to do a flying lead harness and provide guidance on the installation. Note that it requires cutting and tapping into factory wiring and it's essential to cut and tap into the proper wiring. With that said for anyone skilled in automotive wiring it's not terrible.

    Cheers,

  4. #4
    Active Member One Ring AustinEngy's Avatar
    Join Date
    Jul 28 2017
    AZ Member #
    403822
    My Garage
    Beater D2 S8
    Location
    Minneapolis

    I was just joking with my friends about taking my D2 to go watch the Ojibwe Forest Rally but looks like you've already gone and build a sweet offroad D chassis! I'm into offroad Subarus so seeing this kind of build is pretty frickin' sweet. Really dig the custom air suspension controller and the Hellas!
