[nnnick]

thats a sick car! i'm suprised the curvature worked with that bumper! also curious how you made it fit...

[aaron1085]

are these hooked up so thst they are like the stock fogs? Meaning when I unlock at night time, the S6's turn on automatically, etc?

[nnnick]

are these hooked up so thst they are like the stock fogs? Meaning when I unlock at night time, the S6's turn on automatically, etc?

I don't think our fogs do that? Mine don't anyway! So to answer your question, right now, through the oem fog light wiring, no, I have to manually turn the nob and pull it out for the LEDs to power up.

I think I'm going re-wire mine like tgt did here to the fuse box so they are on whenever the ignition is on: http://www.audizine.com/forum/showthread.php?t=313085

[aaron1085]

oh ok. Well if I put my lights on Auto (turn on when its dark), I can go to unlock my car, and the fog lights will turn on along with rear taillights for entire time, until I open my driver's side door.

[Sharkfin]

I think I'm going to try this on my DTM bumper. Wonder if I need to cut into the bumper itself...

[nnnick]

oh ok. Well if I put my lights on Auto (turn on when its dark), I can go to unlock my car, and the fog lights will turn on along with rear taillights for entire time, until I open my driver's side door.

That's cool...I've never had mine do this. If you wire it though the fogs, I don't see why it wouldn't work though!

I think I'm going to try this on my DTM bumper. Wonder if I need to cut into the bumper itself...

Give Umnitza a call and he can get you good measurements, but I pasted his image below as well as another pic on the DTM bumper (looks sick). It looks like you might have to cut away behind the bumper a little from this pic, since the LEDs are so long, but I might be mistaken...at least you don't have to cut away all of the fog light infrastructure! And it seems like any cutting you'd need to do could be covered back up with the grill if you ever decide to part-out or change it up and go back to stock.

You may also have to make a little room behind the LEDs, as they go pretty deep behind the bumper...but probably not much.

[Sharkfin]

^thanks again for more info, he used the s6 grills as well, I would be modifying my DTM grills, pic for reference (barely see them though):

[nnnick]

wow. I didn't realize how much custom work went into the blue one, his opening is entirely different....ouch.

[ngng]

you need to move your LEDs back, it looks REALLY bad sticking out so far.

as for the hardware, and a "kit", the hardware is basic, it's making the kit fit correctly that takes time.

take a look at the blue and black audis. THOSE were done well IMO.

[Sharkfin]

Not really a fan of it on my bumper, but on the s-line it looks good. I'm hoping the opening is big enough. Anyway you can measure the length anytime?

[aaron1085]

I dont know why my fogs do that, guess it's part of the auto lighting package or something!?!
Anyways, I guess we could probably do it with the S6 lights, it'd look frickin DOPE!

[eMacPaul]

I dont know why my fogs do that, guess it's part of the auto lighting package or something!?!
Anyways, I guess we could probably do it with the S6 lights, it'd look frickin DOPE!

It's the coming home feature. There are two small knobs on the dash to the inside of the headlight switch, one for DRL, one for coming home.

[umnitza]

Nick - how's the finished product looking.

[nnnick]

Nick - how's the finished product looking.

Work in progress - should have pictures soon!

[TheRealtor]

^^ my shop followed those pics when they did my LEDs its pretty straight forward, came out great! fitment isnt spot on 100% but will be working on that sometime this winter.

thats a very nice install

keeps a nice oem feel

[Sharkfin]

yeah it looks good

[Bruce Lee]

Hi Nnnick,

Great job you done here. I read your whole post and learn a lot. Tomorrow i will start to do this. Everything is clear and understanding, but can you let me know how you programmed the computer?

You said on post 1
<We vag'd the car so the fogs are independent of headlights and can be turned on with DRLs.?>

Do i have to change the code in option "Central electronic"? Hope you can tell me;

Control Module Coding (only 8EC/8ED)

Select 09 (Central Electronics)
Coding -> Function 07

?xxxx: Chassis

0 - Limousine
1 - Avant

x?xxx: Driving Light Switch

0 - without Rain/Light Sensor (G397)
1 - with Rain/Light Sensor (G397)

xx?xx: Trailer Hitch

0 - without Trailer Hitch
1 - with Trailer Hitch

xxx?x: Headlights

0 - Halogen Headlights w/o Daytime Running Lights
1 - Halogen Headlights with Daytime Running Lights
2 - Bi-Xenon Headlights with Daytime Running Lights
3 - Bi-Xenon Headlights w/o Daytime Running Lights
4 - Bi-Xenon Headlights with Daytime Running/Tail/License Plate Lights

xxxx?: Country

1 - Rest of World/Nordic Countries/Denmark/Croatia/Baltic Countries with Bi-Xenon
2 - Nordic Countries/Denmark/Croatia/Baltic Countries without Bi-Xenon
3 - USA/Canada with Bi-Xenon
4 - Canada without Bi-Xenon
5 - Special Vehicles

[Quattro]

ill post up my setup :D

[nnnick]

I can't remember the codes and how exactly we vag'd it to make the fogs independent of the headlights, although there are a bunch of threads on it so my advice would be to just try a few ways out and see what you like.

Personally, I ended up rewiring the LEDs and not using the fogs because I didn't like having to turn them on all the time, so now they are hardwired to the battery and tap the homelink system so they are on whenever the car is in accessory mode or running...

And Quattro yours looks sick bro!

[Bruce Lee]

Nnnick, if i try it on your way, i would get a fault on my display. I have it now, because i didn't have connect the foglight.

So if you have the code to turn off the foglight then i can connect it directly to the battery.

Hope you can help me

Regards Mike

[Bruce Lee]

Disable the foglight is not possible. But i have a genius idea. I have relocate the wire into the engine bay, and transfer it into engine bay light. So if i have to change oil in the dark i just have to swith on the "foglight".


Just kidding. I am waiting for the resistor

I wire the led to the headlight switch. Now the led always on when i start the car.

One small problem is that i have three wires. 1 is ground and the other two is plus. I have to put the two wires together to let it work. Maybe 1 is +12v and the other is ignition. I wire both to the ignition, no problem at all. But when i start the car, the led goes off for a second. Someone any idea how to fix it. Is the problem cause by the two wire i have melt it together?

Regards Mike

[tgt]

Disable the foglight is not possible. But i have a genius idea. I have relocate the wire into the engine bay, and transfer it into engine bay light. So if i have to change oil in the dark i just have to swith on the "foglight".


Just kidding. I am waiting for the resistor

I wire the led to the headlight switch. Now the led always on when i start the car.

One small problem is that i have three wires. 1 is ground and the other two is plus. I have to put the two wires together to let it work. Maybe 1 is +12v and the other is ignition. I wire both to the ignition, no problem at all. But when i start the car, the led goes off for a second. Someone any idea how to fix it. Is the problem cause by the two wire i have melt it together?

Regards Mike

The blue wire is supposed to be hooked up to the turn signal (so the LED's blink like the S6). I did NOT hook up the blue wire for this reason. If you remove that wire I suspect you'll be good to go.

-tgt

[Jermunji]

nicee. heres my install. not a b7 but heres the pics from my install i did a few months back

Necrobump, beesix, do you have a DIY for how you fitted these?

[Jermunji]

Hey Nick, have any update on a long term review of these? I know that they're a few years old. I'm assuming you transferred them to the S4?
